Devices: APC Back-UPS Pro RS 1500MS2 (Maine), APC Back-UPS Pro NS 1500M2 (Stowe)
1. Context & Objective
The goal of this project was to establish reliable, persistent power telemetry from our primary pfSense firewalls to our Prometheus and Grafana monitoring stack before the winter shutdown.
Topology:
Maine Firewall (campfire – 192.168.76.1): APC UPS connected via USB to a Protectli vault chassis. Runs the FreeBSD nut package (usbhid-ups and upsd daemon listening on TCP 3493).
Collector (bear – 192.168.76.32): Runs nut_exporter in Docker, proxying scrapes between Prometheus and campfire:3493.
Metrics Stack: K3s cluster running Prometheus (scraping every 30s) and Grafana visualizing input voltage, battery load, charge, and online state.
2. Incident: 3:00 AM Telemetry Drop & Root Cause Analysis
The Failure
At 03:00 AM, telemetry went completely flat in Grafana. Prometheus reported:
Plaintext
server returned HTTP status 500 Internal Server Error
read tcp 10.169.0.4:35626->192.168.76.1:3493: i/o timeout
Locally on campfire, the pfSense WebGUI reported Alert: The UPS requires attention / Failed to retrieve status. Restarting the NUT service via the GUI did not recover the connection.
Root Cause
USB Bus Renegotiation: At 3:00 AM (during system log rotation / maintenance), the USB controller momentarily power-cycled its downstream ports, forcing FreeBSD to re-enumerate the bus.
Device Node Drift: The UPS shifted from ugen0.5 down to ugen0.4.
FreeBSD Permission Lockout: FreeBSD created the new character devices (/dev/usb/0.4.0 and /dev/usbctl) with default restrictive permissions (root:operator0644). The unprivileged nut user running usbhid-ups was denied access: Plaintextlibusb1: Could not open any HID devices: insufficient permissions on everything
Daemon Deadlock:usbhid-ups died and left a stale socket file in /var/db/nut/. The upsd server hung indefinitely trying to talk to the dead socket, causing incoming TCP 3493 connections from bear to time out.
Why pfSense Backups Don’t Cover This: Standard pfSense XML backups only save WebGUI application configuration (e.g., nut.conf, user definitions, port assignments). They do not back up or restore low-level FreeBSD OS configuration files like /etc/devfs.conf or custom /usr/local/etc/devd/ rules across upgrades or fresh reinstalls.
3. Runbook: Permanent Fix & Hardening
To make this configuration resilient against USB disconnects, power bounces, and port re-enumerations, we implemented a dual-layer fix on both campfire (Maine) and pivot4port (Stowe).
Because devices behind USB hubs can re-attach dynamically without triggering a full devfs reload, we added a catch-all devd event rule matching the APC USB Vendor ID (0x051d):
During setup, the pfSense Grid Attachment State panel displayed constant red because it was querying output load (network_ups_tools_ups_load) instead of status flags.
Incorrect Query:network_ups_tools_ups_load{...} (returned 4–6% load, breaking the binary 0/1 color mapping).
Corrected Query: Code snippetnetwork_ups_tools_ups_status{instance="camp-pfsense-ups", job="camp-pfsense-ups", flag="OL"} (Returns 1 when Online, 0 when On Battery, mapping cleanly to Dark Green / Dark Red).
The APC 1500 units use an RJ50 (10-pin) to USB Type-A data cable (AP9827). Because the Protectli firewall uses USB-C ports on the front I/O, a compact USB-A Female to USB-C Male adapter connects the UPS directly to the chassis, bypassing unnecessary intermediary powered hubs.
6. Battery Fleet Health Matrix & May 2027 Shopping List
Location
UPS Model
Battery Cartridge
Serial Number
Battery Mfg Date
Health / Action Plan
Camp Main House
Back-UPS Pro RS 1500MS2
APC RBC124
4B2115P17561
2021/04/16
Replace May 2027 (~5.5 yrs old; rapid voltage sag)
Camp Garage
Back-UPS Pro RS 1500MS2
APC RBC124
0B2352L39196
2023/12/29
Healthy (~2.8 yrs old; ~135 min runtime at 4% load)
Stowe Firewall
Back-UPS Pro NS 1500M2
APC RBC124
0B2422L11386
2024/05/28
Healthy (~2.4 yrs old; 100% capacity)
Items to Purchase Before Returning in May:
Replacement Battery Pack:
Part:APC RBC124 (Pre-wired cartridge consisting of two 12V 9Ah AGM lead-acid batteries with inline fuse and APC terminal connector).
Cost: ~$65 – $75 (OEM equivalent by ExpertPower or UPSBatteryCenter) / ~$95 – $105 (Schneider/APC Original).
Chassis USB Adapter:
Part:USB Type-A Female to USB Type-C Male Adapter (low-profile aluminum stub or 6″ pigtail, USB 3.0 OTG compliant, e.g., Anker or CableCreation 2-pack).
